UBIQUITI UAP-AC-LR Unifi UAP-AC-LR Long Range Access Point

UBIQUITI UAP-AC-LR Unifi UAP-AC-LR Long Range Access Point

The UniFi AC LR AP features the latest Wi-Fi 802.11ac technology in a refined
industrial design and is ideal for long-range deployment of highperformance
wireless networks.

UAP-AC-LR
Dimensions 175.7 x 175.7 x 43.2 mm (6.92 x 6.92 x 1.70″)
Weight
With Mounting Kits
240 g (8.5 oz)
315 g (11.1 oz)
Networking Interface (1) 10/100/1000 Ethernet Port
Buttons Reset
Power Method 802.3af/A PoE
24V Passive PoE (Pairs 4, 5+; 7, 8 Return)
Power Supply 24V, 0.5A Gigabit PoE Adapter*
Power Save Supported
Maximum Power Consumption 6.5W
Maximum TX Power
2.4 GHz
5 GHz
24 dBm
22 dBm
Antennas (1) Dual-Band Antenna, Tri-Polarity, 2.4 GHz: 3 dBi, 5 GHz: 3 dBi
Wi-Fi Standards 802.11 a/b/g/n/r/k/v/ac
Wireless Security WEP, WPA-PSK, WPA-Enterprise (WPA/WPA2, TKIP/AES)
BSSID Up to 8 per Radio
Mounting Wall/Ceiling (Kits Included)
Operating Temperature -10 to 70 C (14 to 158 F)
Operating Humidity 5 to 95% Noncondensing
Certifications CE, FCC, IC

Only the single-pack of the UAP-AC-LR includes a PoE adapter.Advanced Traffic ManagementVLAN 802.1QAdvanced QoS Per-User Rate LimitingGuest Traffic Isolation SupportedWMM Voice, Video, Best Effort, and BackgroundConcurrent Clients 250+Supported Data Rates (Mbps)Standard Data Rates802.11ac 6.5 Mbps to 867 Mbps (MCS0 – MCS9 NSS1/2, VHT 20/40/80)802.11n 6.5 Mbps to 450 Mbps (MCS0 – MCS23, HT 20/40)802.11a 6, 9, 12, 18, 24, 36, 48, 54 Mbps802.11g 6, 9, 12, 18, 24, 36, 48, 54 Mbps802.11b 1, 2, 5.5, 11 Mbps
